Model: KD20-50 Casing Tong
| Jaws Available:
9 5/8", 10 3/4", 11 3/4", 13 3/8", 14", 16", 18 5/8" & 20" |
Maximum RPM@35GPM/132 LPM:
High gear: 23rpm
Low Gear: 3rpm
|
Torque Range @ 2600psi/18MPa
High gear: 7500ft-Lbs/10000Nm
Low gear: 50000 ft-Lbs/70000Nm
|
Hydraulic Requirements:
35GPM/132L/min@2610psi/18MPa
*All North American Hydraulics |
Lenght: 83in/2100mm |
Width: 51in/1300mm |
Weight: 1620Kg.
/ 3571Lbs. |
|
|
|
